- Overall dimensions: (Unless otherwise specified, dimensional tolerance is ±0.3).
1.Specifications:
| Receiving Frequency Bands | L1、B1、G1、E1 |
| Anti-Jamming Frequency Bands | L1、B1、G1、E1 |
| Anti-Jamming Capability | single interference≮ 105dB、three interferences≯ 90dB |
| Power Supply Range | 9Vdc~50Vdc |
| Weight | ≤ 400g |
| Dimensions | 130x130x17(mm) |
2.Product Description
| Place of Origin: | China |
| Brand Name: | Signal Plus(OEM&ODM) |
| Model Number: | GPS GLONASS GALILEO L-Band Active GPS Module |
| Certification: | UL/ROHS/ISO14001/FC/ISO9001/EN… |
3.Business Terms Of The Product
| Minimum Order Quantity: | 2-50/300-500/≥500 |
| Packaging Details: | carton |
| Delivery Time: | 14-30Lead time (days) |
| Payment Terms: | Standard payment terms: pay 30% deposit in advance, 70% balance before shipment. Accepted Delivery Terms: FOB, EXW；Accepted Payment Currency: USD, EUR, JPY, CAD,AUD, HKD, GBP, CNY, CHF;Accepted Payment Type: T/T, L/C, PayPal, WesternUnion; |
| Supply Ability: | 100000 |
4.Product Introduction
- Dimensions: 130 mm x 130 mm x 17 mm (see the figure below for specifictolerances).
5. Notes:
- Selection should be optimized based on actual requirements and antenna parameters.
