WiFi Dual-band Omni Directional Antenna

1.Provide a variety of connectors to fit different devices.

2. The signal coverage area can be adjusted according to design requirements.

3. It has a relatively high gain and can enhance the signal strength.

4. With a unique appearance design, it has higher recognizability.

5. Customized design to meet the reliable communication requirements of devices in complex industrial environments.

6. It features installation flexibility and good compatibility.

Inquiry Datasheet

Overview
Inquiry
Related Products

WiFi Dual-band Omni Directional Antenna

Antennas are typically omnidirectional. When installed vertically, the signal radiation is more uniform. Avoid interference from metal objects, walls, or electrical devices, and it is recommended to position the antenna higher than the top of the equipment.

WiFi Dual-band Omni Directional Antenna details

1.Product Description

Frequency Range	2400-2500MHz
Gain	3dBi
Impedance	50ohm
VSWR	2.0 Max
Connector	SMA
Material	TPEE

WiFi Dual-band Omni Directional Antenna details

Precautions:
- Confirm the device operates in the 2.4GHz band (2400–2483.5MHz)—otherwise, efficiency will degrade.
- High-gain antennas (e.g., 5dBi) are suitable for long-range use, but may sacrifice vertical coverage—select based on the scenario.
- For MIMO-supported devices (e.g., Wi-Fi 6), maintain an antenna spacing of ≥λ/2 (~6 cm) to minimize interference.
- Ensure antenna connectors (e.g., SMA, RP-SMA) are compatible with the device—forcing mismatched connectors may cause damage.
- Some antennas have limited temperature tolerance (e.g., -20°C to 60°C)—use industrial-grade products in extreme environments. WiFi Dual-band Omni Directional Antenna factory
